dBTechnologies B-Hype 12

The active two-way speaker series providing a professional sonic performance to all kind of users.

The most accurate sound reproduction combined with aggressive sound pressure levels and enhanced portability.


Technical Data

Speaker Type2-Way Active Speaker


Acoustical data

Usable Bandwidth [-10dB]55 - 20.000 Hz

Frequency Response [-6 dB]61 - 19.500 Hz

Max SPL126 dB

Type HFCompression Driver

HF voice coil1 "

LF12 "

LF voice coil2 "

Crossover Frequency2100 Hz (24 dB/oct.)

Horizontal Dispersionasymmetrical 85° up / 120°down

Vertical Dispersion85° (+25/ -60°)


Amplifier

Amp TechnologyCustom Made

Amp ClassClass D - Passice cooling (convection)

Power Peak400 W


Processor

ControllerDSP 28/56 bit- 48 kHz

LimiterPeak, RMS, Thermal

ControlsVolume, Audio Input Sensitivity, DSP Preset


Input

Main ConnectionVDE

Signal InputBalanced 1xCombo IN (MIC/LINE)

SIGNAL Out(Balanced) 1xXLR OUT (LINK)


Mechanics

HousingPolypropylene

GrilleFull Metal Grille

Handles3 (2 on side 1 on top)

Pole Mount36 mm

Width650 mm (11.61 in)

Height645 mm (21.42 in)

Depth330 mm (11.14 in)

Weight13.9 kg (19.84 lbs)

Angles UpDouble wedge angle 45°
