Directional pattern Supercardioid

Principle of operation Pressure gradient

Cartridge type Pre-polarized condenser

Frequency range 20 Hz - 20 kHz

Frequency range, ± 2 dB, at 20 cm (7.9 in) 80 Hz - 15 kHz with 2 dB soft boost at 10-12 kHz

Sensitivity, nominal, ±3 dB at 1 kHz 6 mV/Pa; -44 dB re. 1 V/Pa

Equivalent noise level, A-weighted Typ. 23 dB(A) re. 20 μPa (max. 26 dB(A))

S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL) Typ. 71 dB(A)

Total harmonic distortion (THD) < 1% up to 131 dB SPL peak

Dynamic range Typ. 108 dB

Max. SPL, peak before clipping 142 dB

Output impedance From MicroDot: 30 - 40 Ω. From DAD4099/DAD6001-BC: 100 Ω

Cable drive capability Up to 300 m (984 ft) with DAD4099 or DAD6001-BC XLR Adapter

Output balance principle Signal balanced with DAD4099 or DAD6001-BC XLR Adapter

Common mode rejection ratio (CMRR) > 60 dB from 50 Hz to 15 kHz with DAD4099 or DAD6001-BC XLR Adapter

Power supply (for full performance) Min. 5 V to max. 50 V through DPA adapter for wireless systems

Current consumption Typ. 1.5 mA (microphone). 3.5 mA with DAD4099 or DAD6001-BC XLR Adapter

Connector MicroDot

Color Black

Weight 27 g (0.95 oz)

Microphone diameter 5.4 mm (0.21 in)

Microphone length 45 mm (1.8 in)

Cable length 1.8 m (5.9 ft)

Cable diameter 1.6 mm (0.06 in) / 2.2 mm (0.09 in)

Polarity +V at MicroDot pin for positive sound pressure (and pin 2 on DAD4099 or DAD6001-BC XLR adapter)

Temperature range -40°C to 45°C (-40°F to 113°F)

Relative humidity (RH) Up to 90%

Gooseneck length 140 mm (5.5 in)
